VehiclesLosi 1/12 Asphalt Late Model
Losi 1/12 Asphalt Late Model
1/12 scale · LOS-3104T1
- Final drive
- 7.76:1
- Tire
- 55.3mm
Open in Top Speedverified
Specifications
Last modified
| Spec | Value | Basis |
|---|---|---|
| Drivetrain | ||
| Pinion | 19TStock | Stock |
| Spur | 59TStock | Stock |
| Transmission & axle | 2.50:1Stock | Stock |
| Spur ÷ pinion | 3.105:1Calculated | Calculated |
| Final drive | 7.76:1Stock | Stock |
| Wheels & tires | ||
| Tire diameter | 55.3mmEstimated | Estimated |
| Rollout | 22.4mm per motor turnCalculated | Calculated |
| Power | ||
| Motor | Not published | |
| Battery | Up to 2SLiPoStock | Stock |
| Performance | ||
| Theoretical top speed | Not published | |
| Vehicle | ||
| Part number | LOS-3104T1 | |
| Scale | 1/12 | |
Stock is as the vehicle ships. Calculated is worked from the stock figures on this page rather than stored beside them, so the two cannot drift apart. Not published means it exists but no source we could find prints it.
How these numbers were settled
Same chassis and gearing as the Losi 1/12 NASCAR, with Hoosier tires instead of Goodyear. Tire OD is derived from this page's own published Roll Out (0.88 in / 22.40 mm per motor revolution) and the published 7.76 total: 22.40 x 7.76 / pi = 55.3 mm.
Sources
Every figure on this page traces to one of these. Where they disagreed, the note above says which was used and why.
