VehiclesTeam Associated RC10 4WD Team Car Kit

Team Associated RC10 4WD Team Car Kit

Name: Team Associated RC10 4WD Team Car Kit
Brand: Team Associated
SKU: 6046

1/10 scale · buggy · 6046

Specs

Gearing Top speed

sourced

Sold without a motor, so there is no stock KV: compare gearing by rollout.

Team Associated RC10 4WD Team Car Kit — Photo: Team Associated (opens in a new tab)

Background

The RC10 4WD Team Car Kit is a 1/10 four-wheel-drive assembly kit with an aluminum tub chassis and independent suspension.¹ The black aluminum tub chassis has front and rear ball differentials, a center belt and CVA driveshafts.¹ Its included tires let the builder complete the rolling chassis before choosing the separately required motor, speed controller and pinion.^1,2 The clear body needs paint, and the radio and steering servo are also supplied by the owner.

Pros

Adjustable front and rear ball differentials provide separate settings for each end.¹

Cons

Motor, speed controller and radio equipment are purchased separately before the vehicle can run.¹

Specifications

Last modified Oct 6, 2026

14 specifications across 5 groups, covering stock setup, dimensions and components.

Spec	Value	Basis
Vehicle
Class The kind of vehicle the maker sells it as. It sets what the car is built to do and which cars it is fair to compare it with. Buggies are low, light off-road cars built for jumps and fast corners on dirt, clay or turf tracks. Drive All four wheels are driven. That gives more grip under power, especially on loose ground. The cost is more parts to maintain. Power Sold without a motor, so you choose the motor, ESC and battery yourself. Rows that depend on the motor say so. Build A kit you build yourself from parts. Most kits come without motor, ESC, servo, radio and battery, and many without tires or a painted body. The manual lists what to add. Scale The maker's nominal size compared with a full-size vehicle. It works more as a class label than a measurement. A 1/10 monster truck is far bigger than a 1/10 touring car, so compare length and weight for real size. Part number The maker's product number for this exact version. A V2, a new color, or a kit instead of an RTR usually has a different number, and parts can differ between them. Check it against your box or receipt before ordering parts.
Class	Buggy
Drive	4WD
Power	Motor not included
Build	Kit
Scale	1/10
Part number	6046
Drivetrain
Pinion The small gear on the motor shaft. Fewer teeth gear the car shorter: quicker acceleration, lower top speed and a cooler motor. More teeth do the opposite. It depends on the motor you fit, so the maker does not list one. Spur The large gear the pinion drives. A bigger spur with the same pinion gears the car shorter. Pinion and spur must have the same pitch, or tooth size, to mesh. Transmission & axle Every reduction after the spur, multiplied together: transmission, differentials and axle gears. It is fixed by the design; the gearing you change is the pinion and spur. Final drive How many times the motor turns for one turn of the wheels. A higher number is shorter gearing: more acceleration and pulling power, less top speed.
Pinion	Not applicable
Spur	81TStock	Stock
Transmission & axle	Not published
Final drive	Not published
Wheels & tires
Tire diameter The outside diameter of the mounted tire, tread to tread. A taller tire covers more ground each turn, which gears the car taller. Race tires wear down over a day, and a smaller tire gears the car shorter.
Tire diameter	Not published
Power
Motor Motor KV is the RPM a motor turns per volt with no load. This vehicle comes without a motor, so there is no stock KV; it depends on the one you fit. Battery The highest LiPo cell count the maker rates the electronics for. This vehicle comes without electronics, so it depends on the ESC and motor you fit.
Motor	Not applicable
Battery	Not applicable
Performance
Theoretical top speed It needs a motor KV, and this vehicle comes without a motor. Fit one and the calculator works it out from the motor's KV and the gearing.
Theoretical top speed	Not applicable

How to read these figures

Stock is as the vehicle ships.
Calculated is worked from the stock figures on this page rather than stored beside them, so the two cannot drift apart.
Not applicable means the vehicle does not come with it, like the motor on a roller or the tires on a race kit.
Not published means it exists but no source we could find prints it.

About these specs

The assembly manual fits an 81T Octalock spur and requires a separately selected pinion, motor and ESC.

Sources

2 source links for this model.

Manual (opens in a new tab)

Maker documents

RC10 4WD Team Car Kit instruction manual (PDF) (opens in a new tab)img2.associatedelectrics.comPDFSupports 1 specification · Background 2Used forMain specsBackground 2

Parts and electronics

RC10 4WD Team Car Kit product page (opens in a new tab)60years.associatedelectrics.comPart pageSupports 1 specification · Background 1Team AssociatedUsed forMain specsBackground 1
