VehiclesTeam Associated DC10 Drift Car RTR
Specifications
Last modified
| Spec | Value | Basis |
|---|---|---|
| Drivetrain | ||
| Pinion | 20TStock | Stock |
| Spur | 81TStock | Stock |
| Transmission & axle | 2.60:1Stock | Stock |
| Final drive | 10.53:1Stock | Stock |
| Wheels & tires | ||
| Tire diameter | Not published | |
| Power | ||
| Motor | 3300KVStock | Stock |
| Motor shaft | Not published | |
| Battery | Not published | |
| Stock motor | Reedy 3300kV brushless motorStock | Stock |
| Battery connector | T-PlugStock | Stock |
| Performance | ||
| Theoretical top speed | Not published | |
| Chassis | ||
| Wheelbase | 257 mm10.1 inStock | Stock |
| Shock oil, front | 10 wtStock | Stock |
| Shock oil, rear | 10 wtStock | Stock |
| Vehicle | ||
| Part number | 30133 | |
| Scale | 1/10 | |
Stock is as the vehicle ships. Calculated is worked from the stock figures on this page rather than stored beside them, so the two cannot drift apart. Not published means it exists but no source we could find prints it.
Gearing parts
| Component | Teeth | Pitch | Bore | Part number |
|---|---|---|---|---|
| Fitted at the factory | ||||
| Pinion | 20T | 48P | 3.175 mm | 1338 (opens in a new tab) |
| Spur | 81T | 48P | Not applicable | 92296 (opens in a new tab) |
Tooth counts are the ones in the specifications above. Pitch is given as metric module (Mod 1, Mod 0.8) or diametral pitch (32P, 48P). They are different standards and are not interchangeable, even where the numbers look close. Bore is the pinion’s hole, listed separately from the motor shaft. Linked part numbers go to the maker's or official distributor's page for that part.
How these numbers were settled
The RTR manual fits a 20T pinion (1338, p. 19) and an 81T 48P Octalock spur (92296, p. 12) in the stock low-motor layout.
- The product page and the RTR press release both print a 2.6:1 transmission ratio, so the total of 10.53:1 is worked out as 81 / 20 x 2.6.
- The maker names a 2S LiPo as the pack to use but does not name the speed control or publish its cell rating, so the cell limit is left blank.
- The diameter of the stock drift tires is not published.
- The gear differential is packed with black grease (6588); the manual suggests 1000cst (80wt) oil for lower-grip surfaces.
- The RTR Combo (30133C) adds a Reedy battery and charger.
Documents
- ManualDC10 Drift RTR instruction manual (Associated PDF) (opens in a new tab)Spur p. 12, pinion and gearing p. 19
Sources
- dc10-drift-car-ready-to-run60years.associatedelectrics.com (opens in a new tab)
- Manual (PDF)img2.associatedelectrics.com (opens in a new tab)
- Manual (PDF)img2.associatedelectrics.com (opens in a new tab)
- RTRportal.associatedelectrics.com (opens in a new tab)
- 2888-new-dc10-ready-to-run-…associatedelectrics.com (opens in a new tab)
- 1338-ASC1338-ft_aluminum_pi…portal.associatedelectrics.com (opens in a new tab)
- 92296-ASC92296-octalock_spu…portal.associatedelectrics.com (opens in a new tab)
Every figure on this page traces to one of these. Where they disagreed, the note above says which was used and why.
